Molds for Plastic Injection

Overview

To utilize 3D data, We have installed the optimal system for each process and we make full use of design and machining technologies to produce molds with the required quality, cost, and delivery.
We offer automotive interior parts such as door trims, console boxes, and handles for an entire product series.

We also have manufacturing and maintenance bases overseas and can handle local procurement.

Processing examples

3D Design

Mold Automotive Door, Movable Side

CAD/CAM

Creation of design/processing data using high-end software

NWe make advantaged design and process with high-quality data by using high-end CAD such as NX (UG) and CATIA and their complementary systems.
It is possible process not only 3D data but also replacede 2D data.

Supported data: DXF, IGES, STEP, NX, CATIA, and others

Analysis Technology

Advance confirmation using two analytical simulations

We perform both resin flow analysis and mold release analysis in our design process to create the optimal mold structure in pursuit of QCD, such as gate positions, number of ejector pins.

Resin flow analysis

Mold release analysis

Dimensional Inspection Technology

Overlay of CAD and scanned data

We verify dimensions by overlaying CAD data of the design and scanned data of the machined product.

Overseas Network

Nine networks in Asia and North America

We have five locations in Asia and four in North America as the NFM Group, under our direct control, and collaborative partners to support our global operations.

Asia

Country	Region	Business form	Weight of molds handled
China	(1) Shenzhen	Design ＆ manufacture	20t
China	(2) Tianjin		20t
Republic of Korea	(3) Seoul		10t
Republic of Korea	(4) Dangjing		10t
Thailand	(5) Bangkok	Maintenance	5t

North America

Country	Region	Business form	Weight of molds handled
U.S.A.	(6) Kentucky	Design modification ＆ maintenance	20t
	(7) Alabama		20t
	(8) Michigan		10t
Canada	(9) Toronto		5t

Inquiry about Products

NGK FINE MOLDS, INC.

Molds Sales Department 0569-23-5835 FAX:0569-23-5839
